AC Hose Type C 13/32 Inch SAE J2064 R134A Automotive AC Hose JUNZE
JUNZE Type C AC Hose in 13/32 inch is designed for systems where a medium-diameter hose handles both suction and discharge duties. The SAE J2064 compliant build includes a nylon barrier layer, synthetic rubber tube, textile reinforcement, and a durable outer cover.
5.0
Color:
Customized
Working Temputure:
-40℃ to 135℃
Refrigerant:
R 134a/R 1234yf
Standard:
SAE J2064, SAE J3062 QC/T664-2019
Product name:
Type C Air Conditioning Hose
Payment Methods:
T/T, PayPal
Package:
Woven Bag, Carton
Material:
EPDM/CSM/IIR+PA+PET
Size:
8.0mm,10.0mm,13.0mm,etc
Terms:
EXW, FOB, CIF, DDU, DDP
Shipping Options:
FedEx, DHL, Air Freight, Sea Freight, Train
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Details
通用空调管2 (2)
C型空调管5
C型空调管2
| Number | Dimension. mm | Inch | I.D. mm | O.D. mm | Wall Thickness mm | Wall Diff Max.mm | Work Pressure | Burst Pressure Min.MPa | Bend Rad | Weight. |
| CH8 | 8.0 | 5/6" | 8.2±0.4 | 19.0±0.5 | 5.4 | 0.4 | 3.5 | 15.0 | 70 | 285 |
| CH10.5 | 10.0 | 13/32" | 10.0±0.5/0.3 | 23.0±0.5 | 6.2 | 0.4 | 3.5 | 15.0 | 85 | 393 |
| CH13a | 13.0 | 1/2" | 13.0±0.4 | 25.4±0.5 | 6.2 | 0.4 | 3.5 | 15.0 | 85 | 332 |
| CH13b | 13.0 | 1/2" | 13.0±0.4 | 23.0±0.5 | 5.0 | 0.4 | 3.5 | 15.0 | 95 | 441 |
| CH16 | 16.0 | 5/8" | 16.1±0.4 | 28.6±0.5 | 6.3 | 0.4 | 3.5 | 15.0 | 105 | 470 |
| C8 | 8.0 | 5/16" | 8.2±0.3 | 15.2±0.4 | 3.5 | 0.4 | 3.5 | 18.0 | 55 | 146 |
| C8a | 8.0 | 5/16" | 8.2±0.3 | 14.8±0.4 | 3.3 | 0.4 | 3.5 | 18.0 | 55 | 132 |
| C10 | 10.0 | 13/32" | 10.2±0.3 | 17.2±0.4 | 3.5 | 0.4 | 3.5 | 18.0 | 65 | 178 |
| C11.2 | 11.5 | 13/32" | 11.2±0.3 | 18.4±0.4 | 3.6 | 0.4 | 3.5 | 18.0 | 70 | 196 |
| C13a | 13.0 | 1/2" | 13.0±0.3 | 19.4±0.4 | 3.2 | 0.4 | 3.5 | 18.0 | 75 | 202 |
| C13.2 | 13.0 | 1/2" | 13.2±0.4 | 20.8±0.5 | 3.8 | 0.4 | 3.5 | 18.0 | 75 | 231 |
| C15.2 | 15.5 | 5/8" | 15.2±0.4 | 22.8±0.5 | 3.8 | 0.4 | 3.5 | 16.0 | 85 | 257 |
| C16.1 | 16.0 | 5/8" | 16.1±0.4 | 23.6±0.5 | 3.75 | 0.5 | 3.5 | 15.0 | 90 | 280 |
Product Information
SAE J2064 Type C, 13/32 inch inner diameter.
Nylon barrier layer for low refrigerant permeation.
Synthetic rubber tube with textile reinforcement.
Outer cover resists heat, oil, and ozone.
Flexible for routing in the engine bay.
Suitable for suction and discharge lines in passenger car AC systems.
Tell us your annual volume and preferred packaging. We will quote FOB Shanghai with a dimensional report from the last five production batches.
FAQ
1
Q : Is this C-type AC hose compatible with common refrigerants such as R134a and R1234yf?
A : Yes, it is specially designed for automotive air conditioning systems, with good compatibility and sealing performance for R134a, R1234yf, and other refrigerants.
