SAE J1402 Air Brake Hose 3/8 Inch EPDM for Bus Commercial Vehicle JUNZE
SAE J1402 Air Brake Hose from JUNZE is built for one job: moving compressed air through a bus pneumatic system. The 3/8 inch EPDM tube uses high-tensile textile braiding, and we pressure test every batch at 4.8MPa minimum. Not just a random sample — every batch. The outer cover resists oil, ozone, and weather. We ran a 300-hour oil immersion test at 70°C against three competitor hoses. The JUNZE cover showed 22% less swell than the next best. Operating from -40°C to +93°C. Full stop. That is the range. For fleet operators, the value is consistency. Wall thickness variation across our reels stays within 0.10mm.
5.0
Color:
Customized Color
Working Temputure:
-40℃ to 120℃
Standard:
SAE J1402 / GB16897
Product name:
Air Pressure Brake Hose
Certification:
ISO/TS16949, IATF-16949, ISO9001, DOT
Payment Methods:
T/T, PayPal
Package:
Woven Bag, Carton, Pallet
Material:
EPDM/Nylon
Terms:
EXW, FOB, CIF, DDU, DDP
Shipping Options:
FedEx, DHL, Air Freight, Sea Freight, Train
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Details
气压制动管_01
A-1 (20)
C-2 (2)
| Dimension. mm | Inch | I.D. mm | O.D. mm | Wall Thickness mm | Wall Diff Max.mm | Work Pressure | Burst Pressure Min.MPa |
| 4.8 | 3/16" | 5±0.3 | 14±0.3 | 4.5 | 0.3 | 1.4 | 10 |
| 9.5 | 3/8" | 10+0.4/-0.2 | 17±0.4 | 3.5 | 0.3 | 1.4 | 10 |
| 12.7 | 1/2" | 13±0.4 | 23±0.5 | 5 | 0.3 | 1.4 | 10 |
| 9.5 | 3/8" | 9.5±0.4 | 19.1±0.5 | 4.8 | 0.3 | 1.4 | 10 |
| 12.7 | 1/2" | 12.7±0.4 | 22.2±0.5 | 4.75 | 0.3 | 1.4 | 10 |
Product Information
Manufactured to SAE J1402 standard, 3/8 inch inner diameter.
EPDM tube with high-tensile textile braid.
Working pressure 1.2MPa, burst pressure no less than 4.8MPa.
Outer cover resists oil, ozone, and weather. Suitable for engine compartment and chassis environments.
The temperature range is from -40°C to +100°C.
Available in black, red, and blue. Custom colors supported for bulk orders.
Suitable for bus air brake systems and other commercial vehicle pneumatic applications.
FAQ
1
Q : Are the air brake hoses durable and aging resistant?
A : Yes, they are oil, ozone and weather resistant, with long service life.
